DC003 DC Power Jack

DC Power Jack Product Overview

The DC Power Jack is a compact and reliable power interface designed for low-voltage electronic devices requiring stable and efficient DC power input. Commonly used as a dc jack, dc jack plug, or dc female socket, this component enables secure connection between dc plugs and internal power circuits.

Engineered for modern electronics, the dc charging jack supports miniaturized designs while ensuring safe power transmission, making it ideal for smart wearables, smart home devices, and drone accessories. With optimized contact resistance and robust structural design, this dc power jack delivers consistent performance even in space-constrained applications.

Product Features of DC Power Jack

1. Mini Horizontal–Vertical Design

• Optimized internal structure stabilizes power flow in ultra-compact devices

• Suitable for dense PCB layouts and lightweight electronics

• Ideal for wearable tech and drone battery charging ports

2. Reverse-Polarity Guard

• Built-in protection prevents damage caused by incorrect dc jack plug insertion

• Enhances safety for sensitive electronic components

• Reduces failure rate in consumer and industrial products

3. Quick PCB Mounting

• Solder pins are compatible with standard PCB footprints

• Fast and efficient assembly, typically completed within 90 seconds

• Improves production efficiency for mass manufacturing

4. Ultra-Compact Size

• Up to 50% smaller than traditional dc power jack designs

• Enables slimmer product profiles and modern industrial design

5. Efficient Power Transfer

• Supports 1A continuous current

• Low contact resistance (max. 20mΩ) minimizes energy loss

• Ensures stable performance for dc charging jack applications

6. Dust-Proof & Durable

• IP50-rated structure blocks fine dust particles

• Designed for over 5,000 insertion cycles

• Offers 2× longer lifespan compared to conventional dc female sockets

Advantages of Using Our DC Power Jack

• High Reliability: Stable electrical contact reduces power interruption risks

• Enhanced Safety: Reverse-polarity protection safeguards devices and users

• Space-Saving Design: Perfect for compact electronics and wearable devices

• Long Service Life: Durable materials ensure extended usage cycles

• Easy Integration: Compatible with common dc plugs and PCB standards

These advantages make the dc jack an excellent solution for manufacturers seeking long-term reliability and efficient power connectivity.

Product Applications of DC Power Jack

Smart Wearables

Example: Fitbit Sense-style smartwatches

• Miniaturized dc charging jack supports slim and lightweight designs

• Ensures safe and stable charging for daily wearable use

Smart Home Sensors

Example: Philips Hue Motion Sensor

• Compact dc female socket fits neatly into small enclosures

• Dust-proof performance supports long-term indoor operation

Drone Accessories

Example: DJI Mini 3 Pro battery charging port

• Lightweight dc power jack minimizes overall drone weight

• Stable power input ensures safe and efficient battery charging

Conclusion

With its compact size, high durability, and reliable electrical performance, this DC Power Jack is a versatile power solution for next-generation electronics. Whether used as a dc jack, dc jack plug interface, or dc charging jack, it meets the demanding requirements of smart wearables, smart home devices, and drone accessories.
