DC088 DC Power Jack

Product Description

The DC power jack, also referred to as a power jack, DC jack, DC jack connector, or DC power socket, is a compact and reliable electrical connector designed to deliver stable DC power input to electronic devices. As a core component within DC power plugs and sockets systems, it enables safe and efficient power transfer between external adapters and internal circuitry using compatible DC plugs.

Engineered for modern compact electronics, this DC jack connector supports low-profile and hidden installation designs while maintaining excellent electrical and mechanical performance. Whether integrated into smart home products, portable medical devices, or industrial control equipment, the DC power jack ensures consistent current delivery, secure mating with DC power plugs and sockets, and long-term operational durability.

Key Features

• Compatible with standard DC plugs and DC power plugs and sockets

• Precision-designed DC jack connector for stable electrical contact

• Low contact resistance (≤30mΩ) for efficient DC power socket performance

• Smooth insertion force (3–20N) to protect the DC jack from misalignment

• SMT and through-hole mounting options for flexible PCB design

• Compact power jack structure for slim and space-constrained devices

• High insulation strength and reliable electrical isolation

• Designed for high-cycle plug and unplug operations

Product Advantages

Optimized Power Transmission

The DC power jack supports stable current delivery even in compact layouts. Low-resistance contact design minimizes voltage drop, heat generation, and energy loss across the DC power socket, ensuring efficient power transfer.

Accurate Plug Alignment

The precision-guided DC jack connector ensures smooth engagement with DC plugs, reducing mechanical stress and preventing damage caused by improper insertion.

Efficient PCB Assembly

With SMT-compatible designs, the DC jack allows fast and automated PCB installation, significantly improving production efficiency for high-volume manufacturing.

Long-Term Mechanical Reliability

Tested for more than 5,000 mating cycles, this power jack delivers consistent performance throughout the product lifecycle, outperforming conventional DC power plugs and sockets solutions.

Cost-Effective Design

Optimized material usage and robust construction reduce overall production costs while maintaining the electrical stability required of a high-quality DC power socket.

Application Scenarios

Smart Home Appliances

Used as a concealed DC power jack in smart controllers and thermostats, providing clean aesthetics and reliable power input.
Example: Nest Thermostat-style hidden charging ports.

Portable Medical Devices

Ensures safe and precise power delivery through a secure DC jack connector, essential for medical-grade electronics.
Example: Dexcom G7 glucose monitor charging interfaces.

Industrial Control Systems

Applied in sensors, gateways, and controllers where durable DC power plugs and sockets must withstand vibration, dust, and long-term operation.
Example: Siemens SIMATIC industrial sensor nodes.

Consumer Electronics

Widely used in routers, displays, handheld devices, adapters, and chargers requiring compact DC jacks and standardized DC plugs.

Summary

This DC jack / DC power jack / DC power socket combines compact design, low contact resistance, and high durability to meet the power input requirements of modern electronic devices. As a dependable DC jack connector within DC power plugs and sockets systems, it provides efficient power transfer, smooth plug engagement, and long service life—making it an ideal power jack solution for consumer, medical, and industrial applications.

KKG Electronics, each part of the use of temperature-resistant materials, high-temperature testing equipment 260 ℃ for 5 minutes, the appearance of the product does not change!

High effiency of production, shipped in 1 day after payment.

Q1: May I have free samples?
A: Sure, but we need to confirm the product details before shipment. Besides, it is better to provide the AI format artwork to us.

Q2: Do you provide anti-static protection for sensitive electronics integration?

A:Yes, all connectors include ESD shielding (15kV minimum) to protect against static discharge during handling or operation.

Q3: What are the lead time and packaging options for bulk orders?

A: Standard Orders: 15-20 days, packed in anti-static tape and reel.

    Custom Requests: 25-30 days, with vacuum-sealed moisture barrier bags for humidity-sensitive environments.

Q4: How do your connectors handle high-temperature soldering processes?

A: The nylon housing withstands reflow soldering up to 260°C for 10 seconds. Precise pin alignment prevents warping during PCB assembly.

Q5:How do you package the goods?

A: We will package the swtiches in reels or in anti static bag with covering air bubble films. Besides, they will be putting into a inner box and then into a outer carton.
