Product Details
Place of Origin: Dongguan China
Brand Name: KKG
Certification: CE / SGS / ISO9001
Model Number: DC099
Payment & Shipping Terms
Minimum Order Quantity: 500pcs
Price: Negotiate
Packaging Details: Plastic bag+ inner box bubble+ inner box in Carton
Delivery Time: 3-5 Days
Payment Terms: T/T, L/C, Western Union
More Details please find the below websties:
| Characteristics | Specification |
|---|---|
| Rating | 1.0A 30V |
| Actuating force | 3~20N |
| Dimension | 10.50mm* 6.50mm |
| Operating life | 5,000 cycles |
| Dielectric Strength | AC500V |
| Contact Resistance | 30mΩ Max |
KUKA KR AGILUS-style Controller DC Power Jack's Product Operating Principle
Orthogonal dual-spring contacts split current across horizontal/vertical paths (IEC 60512-8-4 compliant), reducing resistance by 45% and eliminating hot spots. The directional keyway ensures ±0.3° plug alignment precision, while 2.0kV dielectric insulation prevents arcing. Through-hole terminals maintain ＜5mΩ impedance under 20G vibration (MIL-STD-810G tested).
ABB Terra 94-style Charger DC Power Jack's Product Functions
--Heavy-Duty Current: 8A 48VDC sustained load with ＜0.15V drop (3X industry standard).
--Industrial Construction: 2.0mm thick copper alloy springs & anti-corrosion nickel plating.
--Extreme Environment: UL94 V-0 + IP67 certification for dust/water/oil resistance.
--Arc Suppression: Reinforced silicone shroud withstands 50kV/m³ arc energy.
--Automated Assembly: Compatible with wave soldering (30,000 units/hour throughput).
Schneider APC-style Rack Interface DC Power Jack's Product Applications
Industrial Robotic Arms
Example: Deployed in KUKA KR AGILUS-style controllers for motor power terminals.
EV Fast Charging Stations
Example: Integrated into ABB Terra 94-style chargers for auxiliary 48V DC ports.
Data Center PDUs
Example: Powers Schneider APC-style racks with high-current DC backup interfaces.
KKG Electronics, each part of the use of temperature-resistant materials, high-temperature testing equipment 260 ℃ for 5 minutes, the appearance of the product does not change!
High effiency of production, shipped in 1 day after payment.
Q1: What industries do your PCB/PCBA services support?
A: Our PCB/PCBA solutions serve medical, automotive, energy, measurement, and consumer electronics sectors, adhering to industry-specific compliance and performance standards.
Q2: What is the process for developing custom molds?
A: Custom molds require feasibility analysis, cost negotiation, and lifespan forecasting. Submit end-product details to initiate a 5-day technical review.
Q3: Can I submit non-AI design files for quotations?
A: Yes, Gerber files, CAD models, or schematics are acceptable. AI formats ensure faster turnaround but are not mandatory for initial quotes.
Q4: What warranty and technical support accompany orders?
A: 12-month warranty against manufacturing defects. 24/7 engineering support via email/chat for integration troubleshooting.
Q5: Do you provide industry-specific certifications for medical devices?
A: Medical-grade products include ISO 13485 documentation, sterilization reports, and biocompatibility testing data upon request.
