Product Details
Max. Voltage: | 50VDC | Operating Temperature: | -30℃to+85℃ |
Max. Current: | 50mA | Whether The Smart: | No |
Contact Resistance: | 100mΩ Max | Type: | SMD Tact Switches |
LED: | No | Travel: | 0.25±0.1mm |
Life: | 1000000circle | Withstanding Voltage: | 250VACfor1min |
Rated Current: | 50mA.12VDC | Operating Force: | 100g/160g/260g |
Tact Switch's Specification
Brand : | KKG |
Housing material: | plastic |
Terminal material: | stainless steel |
Dimension: | 3.0*2.75×H |
Height range: | 1.3/1.4/1.45/1.6mm |
Max. Current: | DC 50mA |
Max voltage: | 12V |
Button color: | Red / customer requested |
