Switch Series Product Collection KKG Developing with the Green Planet
Product Details
Place of Origin: Dongguan China
Brand Name: KKG
Certification: CE / SGS / ISO9001
Model Number: DC055
Payment & Shipping Terms
Minimum Order Quantity: 500pcs
Price: Negotiate
Packaging Details: Plastic bag/Reel for goods+ inner box bubble+ inner box in Carton
Delivery Time: 3-5 Days
Payment Terms: T/T, L/C, Western Union
More Details please find the below websties:
Mini surveillance cameras 2.5mm DC Power Jack's Product Operating Principle
The 2.5mm DC Power Jack establishes an electrical connection between an external power source and an electronic device. The inner pin carries the positive voltage, while the outer sleeve carries the negative or ground connection, ensuring efficient and stable power transfer.
GPD Win 3 Keyboard 2.5mm DC Power Jack's Product Functions
1.Power Delivery: Transfers power from external adapters to devices.
2.Stable Connection: Provides a secure and uninterrupted power link.
3.Space Efficiency: Compact design saves valuable PCB space.
Bose SoundLink Mini 2.5mm DC Power Jack's Product Applications
1.Consumer Electronics:
Portable Fans: EasyAcc Mini Fan, OPOLAR Battery Operated Fan (powered by adapters).
Small Audio Systems: Bose SoundLink Mini, Sony Cube Speaker (for steady power supply).
2.Portable Devices:
Handheld Gaming Consoles: Anbernic RG351P, GPD Win 3 (to connect compact chargers).
Wearable Tech: Health monitoring devices like fitness trackers or compact smartwatches.
3.Industrial Use:
IoT Devices: Raspberry Pi-based systems, ESP32 development boards (for efficient power management).
Security Gadgets: Mini surveillance cameras or alarm systems for flexible powering.
| Rating | 1.0A, 30V DC |
| Contact Resistance | 30mΩ Max(initial) |
| Insulation Resistance | 100mΩ Min(250VDC) |
| Dielectric Strength | AC 500V(50Hz for 1minute) |
| Actuating Force | 3-20N |
| Environment Temperature | -30℃~70℃ |
| Electrical Life | 5,000 Cycles |
KKG Electronics, each part of the use of temperature-resistant materials, high-temperature testing equipment 260 ℃ for 5 minutes, the appearance of the product does not change!
High effiency of production, shipped in 1 day after payment.
Q1: What kind of industrial PCB/PCBA services do you support?
A: Our PCB/PCBA solutions serve a wide range of sectors, including healthcare, automotive, energy, measurement instruments, and consumer electronics.
Q2: Can you send us samples?
A: Yes, we provide free samples! Customers are only required to cover the shipping costs.
Q3: How do you package our products?
A: We prioritize secure packaging by using both inner boxes and sturdy outer cartons to ensure the goods arrive safely.
Q4: How do you ensure product quality?
A: All our products undergo rigorous 100% testing before dispatch. We guarantee reliable performance and long-lasting durability.
Q5: How is the shipping cost calculated?
A: Shipping charges depend on the quantity of the order and the destination location.
