TRRS IP67 3.5mm DIP Audio Connector Jack丨PJ-9311

Schiit Magni 3+ Headphone Amplifier Headphone Jack's Product Operating Principle

1. Secure Mounting: The through-hole pins are soldered directly through the PCB, creating an exceptionally strong physical bond that resists mechanical stress and vibration.

2. Signal Transmission: When a plug is inserted into this 3.5 mm earphone jack, its internal contacts establish a secure connection, ensuring clear and stable stereo audio transmission.

3. Durable Performance: Engineered for a long operational life, the mechanism is rated for a minimum of 5,000 insertion and removal cycles, guaranteeing consistent reliability.

Siglent SDS1104X-E Oscilloscope Headphone Jack's Product Functions

1. Stable PCB Integration: The DIP mounting style provides maximum mechanical strength, making it ideal for high-use ports or devices subject to physical strain.

2. Stereo Audio Interface: This 3.5 mm headphone jack delivers a standard connection for stereo headphones, auxiliary cables, and other audio peripherals.

3. Long-Term Reliability: Built to endure 5,000 cycles with a secure operating force of 3-30N, it is a dependable choice for quality audio equipment.

4. High-Fidelity Connection: Ensures a clean signal path with a low contact resistance of 50mΩ (Max) for optimal audio performance

Make Noise Maths Eurorack Synthesizer Module Headphone Jack's Product Applications

1. Domestic Audio: Integrated into the Schiit Magni 3+ Headphone Amplifier, providing a durable and high-quality front-panel output for home audio enthusiasts.

2. Industrial Test Equipment: Used in the Siglent SDS1104X-E Oscilloscope, serving as the trigger output port, where its robust mounting ensures reliability in a busy lab environment.

3. Professional Music Production: Serves as a patch point on the Make Noise Maths Eurorack Synthesizer Module, where the durable 3.5 mm earphone jack is essential for withstanding frequent patching by musicians.
