KKG DC019A: Vertical DC Power Socket with Panel Mount

Allen-Bradley PanelView DC Power Cable's Product Introduction

As a leading dc socket cable factory, KKG Electronics Co., Ltd. is proud to present the DC019A, a top-tier power connector designed for superior durability and electrical performance. This vertical DC power jack is distinguished by its integrated panel mount, providing a secure and stable fixture to the chassis of any electronic device. Engineered to handle a high-current load of 5A at 30V, it is the ideal solution for applications requiring more power than standard connectors can deliver. The jack's robust build quality ensures a long operational life, with an insertion and extraction force calibrated between 3N and 20N for a connection that is both firm and user-friendly.

The internal design of the DC019A is meticulously crafted for optimal power transmission. The low contact resistance of 30mΩ or less minimizes power loss and heat generation, ensuring efficient operation even under sustained load. Furthermore, its high insulation resistance of over 100MΩ and a dielectric strength of AC 500V protect the connected device from electrical shorts and interference. This makes the dc socket with mother board integration a safe and reliable choice. Built to perform in a wide range of environments, it operates flawlessly in temperatures from -30℃ to +70℃. Choose the KKG DC019A for a power connection that delivers unmatched reliability and safety.

Cisco Catalyst series DC Power Cable's Product Operating Principle

1. Secure Mounting: The threaded body and nut allow the socket to be firmly fastened to an enclosure or panel, ensuring mechanical stability and preventing movement.

2. Power Transmission: When a compatible barrel plug is inserted, the internal spring contacts grip the center pin and outer sleeve, creating a low-resistance path for DC power.

3. Stable Connection: The vertical through-hole pins are soldered directly to a PCB (dc socket with mother board), creating a durable electrical and physical link for power transfer.

LaCie's DC Power Cable Product Functions

1. Power Input: Provides a standardized and secure input port for receiving DC power from an external adapter or power supply.

2. High-Current Delivery: Safely handles a continuous load of up to 5A, making it suitable for power-hungry devices.

3. Durable Interface: With an insertion and extraction force of 3N~20N, it is designed for repeated use without losing connection integrity.

4. Device Protection: High insulation and dielectric strength protect the host device from potential electrical faults.

• Industrial Automation: Used as the primary power input jack on programmable logic controllers (PLCs) and HMI panels, such as the Allen-Bradley PanelView series, requiring a secure, vibration-resistant connection.

• Telecommunications: Integrated into networking equipment like routers and switches, for instance, the Cisco Catalyst series compact switches, where reliable power is critical for uninterrupted operation.

• Consumer Electronics: Serves as the charging port on high-performance consumer devices and docking stations, such as the power input for external hard drive enclosures from brands like LaCie.
