PJ-6344A: 6.35mm Stereo Audio Jack for Electronics

Roland TD-17 Sound Module Headphone Jack's Product Introduction

KKG Electronics Co., Ltd. proudly presents the PJ-6344A, a versatile and durable audio connector that reflects our 15+ years of manufacturing expertise. This 6.35 jack is specifically designed for developers and engineers who require a dependable audio interface for their products. Its robust construction ensures a stable connection, capable of withstanding the rigors of frequent use, making it an ideal choice for a wide array of audio equipment, from professional studio gear to everyday consumer electronics. The PJ-6344A is built to last, providing a secure and reliable link that preserves the integrity of your audio signal.

Engineered for seamless integration, this female audio jack features a through-hole, DIP-style design that creates a strong mechanical bond with the PCB. This is crucial for products that experience physical stress, ensuring the solder joints remain intact. The component's compatibility with modern reflow soldering processes makes it perfect for streamlined, high-volume manufacturing, reducing assembly time and cost.

With an exceptional electrical life of 5,000 cycles, the PJ-6344A offers long-term reliability. Its low contact resistance (50mΩ Max) and high dielectric strength (AC500V) guarantee a clean, noise-free signal path. This meticulous attention to electrical performance ensures that the audio remains pure and unaltered, from input to output. By choosing the KKG PJ-6344A, you are investing in a component that delivers consistent quality and performance, enhancing the value and reliability of your final product. Trust KKG to provide the foundation for every great audio experience.

Behringer ULTRAPATCH PRO PX3000 Headphone Jack's Product Operating Principle

1. Secure Engagement: When a 1/4 inch plug is inserted, precision-engineered internal contacts firmly grip the plug, ensuring a stable and continuous electrical connection for audio signals.

2. PCB Integration: The DIP pins are designed to pass through holes in a printed circuit board, where they are soldered to create a strong, lasting electromechanical bond.

3. Signal Integrity: The component is designed to isolate left, right, and ground channels effectively, preventing crosstalk and preserving the quality of the stereo audio signal

Marshall JCM800 Headphone Jack's Product Functions

1. Audio Interface: Provides a universal 1/4 inch connection point for audio input and output on a wide range of electronic devices.

2. Durable Connectivity: Guarantees a reliable link for headphones, musical instruments, and external audio sources with a 5,000-cycle life.

3. Manufacturing Efficiency: The 6.35 jack is optimized for reflow soldering, streamlining the production process for electronic assemblies.

4. Signal Purity: Ensures minimal signal degradation with low contact resistance, delivering clear and high-fidelity audio to the end-user.

• Musical Instruments: Serves as the high-impedance instrument input on legendary guitar amplifiers like the Marshall JCM800, providing a famously rugged connection point for guitars.

• Consumer Electronics: Used as the main headphone output on electronic drum modules, like the Roland TD-17 Sound Module, offering a reliable connection for practice sessions.

• Professional Audio Equipment: Used extensively in studio patchbays, like the , where dozens of jacks are needed for routing signals between devices.

KKG Electronics, each part of the use of temperature-resistant materials, high-temperature testing equipment 260 ℃ for 5 minutes, the appearance of the product does not change!

We ensure high production efficiency and ship your order within 7 days after payment.
