Are you a factory or a trading company?
Answer: We are a factory, we can guarantee our price is first hand, very cheap and competitive.
How is the quality control in your factory?
Answer: All products will be 100% checked before shipment.
How to contact us?
Tel: 86-13377785035
Wechat: kkg-vivian
Email: xyy@kkg.tw
WhatsApp: +8613377785035
| product name | tact switch |
| travel | 0.25±0.1mm |
| rating | 50m A DC12V |
| Contact resistance | ≤50MΩ |
| Operating force | 250±30gf |
| stroke | 0.30±0.1mm |
| Insulation resistance | ≥100MΩ |
| Electric strength | 250V 50HZ 1Min. |
| Life span | ≥100000 times |
| Waterproofing class | IP67 |
| Anti-silver migration | 60V,85℃,90%RH/60H |
2.IP67 Tact Switches' Specification
The waterproof tact switch own black and red two color button,and 5 kinds of heigh:3.3 4.3 4.5 5.0 7.0mm
| Sepe | Contact resistance | Insulation resistance | Travel |
| Blackhead 3.3H | ≥100MΩ | 100MΩ | 5±0.5mm |
| Redhead 4.3H | ≥100MΩ | 100MΩ | 5±0.5mm |
| Redhead 4.5H | ≥100MΩ | 100MΩ | 5±0.5mm |
| Redhead 5.0H | ≥100MΩ | 100MΩ | 5±0.5mm |
| Redhead 7.0H | ≥100MΩ | 100MΩ | 5±0.5mm |
3.Red Button 6*6 Tactile Switches' Application
The main applications of this waterproof touch switch are: household intelligent appliances, digital electronics, security products, robotics industry
| stroke | 0.30±0.1mm |
| Electric strength | 250V 50HZ 1Min. |
| Life span | ≥100000 times |
| Waterproofing class | IP67 |
| Anti-silver migration | 60V,85℃,90%RH/60H |
Q:May I get free samples?
A:Sure, 10-20 pcs of free samples are available for normall models. We need to confirm height, operation force and price before shipment.
Q:Can you accept small order, like 1000 pcs , 2000 pcs ?
A:Sure, but we suggest you buy more, because it really can save you time and freight charge in the near future.
Q:How about your quality control?
A:All the products will be 100% checked before the shipment.
Q:Are you a factory or trading company?
A:We are factory, we can provide competitive price.welcome to visit our factory.
