Our DIP switches are precision-engineered components designed for reliable performance in a wide range of electronic applications. Available in slide, rotary, and piano types with multiple configurations from 1 to 12 positions, they feature options such as surface mount or through-hole mounting, gold or tin-plated contacts, and custom actuator designs. These switches ensure excellent electrical conductivity, low contact resistance, and high durability—tested for up to 25,000 cycles. Fully customizable in pin layout, pitch, marking, and packaging, they are ideal for circuit control, signal switching, and address setting in embedded systems, industrial control units, and consumer electronics.

Features

• Multiple Configurations
  Available in 1 to 12 positions with slide, rotary, and piano-type options to suit various circuit needs.

• Mounting Versatility
  Supports both Surface Mount (SMD) and Through-Hole (THT) installation for different PCB layouts.

• Reliable Contact Performance
  Low contact resistance and high conductivity with optional gold or tin-plated terminals.

• Durability & Lifespan
  Designed for up to 25,000 mechanical cycles, ensuring stable operation over time.

• Customizable Design
  Flexible customization for actuator height, color, pin pitch, terminal layout, and housing marking.

• RoHS & REACH Compliant
  Manufactured using environmentally friendly materials in accordance with international standards.

• Packaging Options
  Supplied in tape & reel, tube, or tray format for manual or automated assembly processes.

• Wide Application
  Ideal for use in consumer electronics, industrial automation, communication equipment, and smart control systems.

Applications

• Consumer Electronics
  Used in remote controls, set-top boxes, digital cameras, and gaming devices for mode or address setting.

• Industrial Control Systems
  Ideal for machinery interfaces, signal configuration, and manual parameter adjustment.

• Smart Home Devices
  Applied in smart switches, access control systems, and home automation controllers.

• Medical Equipment
  Integrated into control panels for medical monitoring or diagnostic devices.

• Communication Equipment
  Enables address or mode configuration in routers, network switches, and RF devices.

• Automotive Electronics
  Suitable for dashboard controls, ECU testing modules, and onboard signal management.

• Measurement & Testing Instruments
  Used to set operational modes, thresholds, or calibration states in lab-grade equipment.

• Security & Alarm Systems
  For code setting, channel selection, or manual override in alarm and surveillance units.

Product Advantages

• High Reliability
  Engineered for up to 100,000 mechanical cycles, ensuring long-term stable performance in critical applications.

• IP67 Protection
  Fully sealed structure provides excellent resistance to dust and water, suitable for harsh or outdoor environments.

• Precision Control
  Consistent actuation force (250 ± 40gf) and short travel distance (0.25 ± 0.1 mm) enable accurate and responsive switching.

• Low Contact Resistance
  Ensures reliable signal transmission with ≤ 50mΩ, reducing power loss and signal noise.

• Compact & Flexible Design
  Standard 12 × 12 mm size and adjustable 6–15 mm height meet a variety of PCB and enclosure design needs.

• Versatile Customization Options
  Supports tailored pin layouts, actuator colors, packaging methods, and marking to fit unique application demands.

• RoHS-Compliant Materials
  Made with environmentally friendly materials in line with global compliance standards.

• Strong Manufacturing Support
  Quick sampling, low MOQ options, and responsive technical service to support both standard and OEM/ODM projects.

Frequently Asked Questions (FAQ)

1. What is a DIP switch?

A DIP (Dual Inline Package) switch is a small, manual switch used to configure settings on a circuit board. It allows users to select different modes, settings, or addresses for a device or system by flipping individual switches in a specific pattern.

2. What are the different types of DIP switches available?

We offer various types of DIP switches, including:

• Slide-type: Typically used for simple on/off settings.

• Rotary-type: Used for precise adjustments, such as volume or frequency settings.

• Piano-type: For compact spaces where high-density configuration is required.

• SMD (Surface Mount Device): For modern PCB designs with smaller footprints.

3. What is the operating voltage and current rating?

Our DIP switches are rated for DC 12V and 0.5A, making them suitable for low-voltage electronic control applications.

4. How long do your DIP switches last?

Our DIP switches are designed for up to 100,000 mechanical cycles, ensuring they provide reliable performance over long periods of use.

5. Are your DIP switches waterproof?

Yes, our DIP switches feature an IP67 protection rating, which means they are resistant to dust and water, making them ideal for outdoor or industrial applications.
