2.0 Female Mini Usb-B Connector

Product Description

The Mini USB B Connector, also known as mini USB B, is a compact, high-performance connector designed for USB 2.0 devices. It provides a secure and reliable connection between USB cables and ports, enabling both high-speed data transfer and stable power delivery.

When a mini USB B male plug is inserted into a USB mini B female socket, the contacts align to establish a robust electrical connection. The connector supports 4 or 5 pins, allowing simultaneous data communication and power supply. It is ideal for devices with limited space that require compact connectivity, such as portable electronics, embedded systems, and IoT solutions.

The Nokia Mini USB-B Connector and other high-quality variants provide durability, stability, and long service life, making them suitable for both consumer and industrial applications. Additionally, USB C to Mini B adapters can be used to bridge modern devices with legacy ports.

Key FeaturesHigh-Speed Data Transfer

• Facilitates USB 2.0 communication for syncing files, backups, and peripheral connections.

• Reliable Power Supply
  Supports 5V DC power delivery for charging portable devices or powering small embedded systems.

• Compact Design
  Space-saving mini B connector suitable for tight device layouts without compromising performance.

• Durable and Robust
  Rated for 1.5A per contact terminal, 30V DC, and insulation resistance of 1000 MΩ, ensuring reliable operation.

• Wide Compatibility
  Works with older smartphones, MP3 players, digital cameras, and other mini USB B devices, and can be paired with USB C to Mini B adapters.

Advantages

1. Versatile Functionality
   Supports both data and power transfer, reducing the need for multiple connectors.

2. Durable for Long-Term Use
   High-quality contacts and insulation withstand repeated insertions and harsh environments.

3. Compact and Space-Saving
   Ideal for devices where board space is limited, while maintaining high performance.

4. Ease of Integration
   Compatible with USB 2.0 standards and easy to integrate into embedded systems, industrial equipment, and IoT devices.

5. Legacy Device Support
   Ensures continued use of older electronics with mini USB B interfaces alongside newer USB-C devices.

Applications

• Consumer Electronics: Used in MP3 players, digital cameras, older smartphones, and portable media devices.

• Embedded Systems: Perfect for compact embedded devices requiring USB data communication or power supply.

• Industrial Equipment: Found in diagnostic tools, data loggers, and small-scale control systems.

• IoT Devices: Integrated in smart home and IoT solutions requiring compact connectors for data and power.

• Automotive Electronics: Used in in-car systems, telematics, and diagnostic equipment where size constraints are critical.

Technical Parameters

• Current Rating: 1.5A/contact terminal

• Voltage Rating: 30V DC

• Contact Resistance: ≤30 mΩ

• Dielectric Withstanding Voltage: 500V AC at sea level

• Insulation Resistance: ≥1000 MΩ

 KKG Electronics, each part of the use of temperature-resistant materials, high-temperature testing equipment 260 ℃ for 5 minutes, the appearance of the product does not change!

High effiency of production, shipped in 1 day after payment.
