6-Port PCB Mount Audio Video Socket

Behringer Xenyx 1202 RCA Audio Socket's Product Introduction

KKG Electronics presents the RCA-603, a comprehensive rca jack female module designed to maximize connectivity in home entertainment systems. This 6-port matrix integrates six individual connectors into a single block, drastically reducing the PCB footprint compared to using separate jacks. As a dedicated home theatre rca socket, it is perfectly configured to handle complex signal arrays, such as a full 5.1 analog surround sound output or a combination of Component Video (YPbPr) and Composite inputs. The unit ensures a stable rca socket connection for each channel through high-retention internal springs and isolated signal paths that prevent crosstalk. Engineered for durability, the RCA-603 withstands the thermal and mechanical stresses of automated soldering. Its standardized layout makes it an essential rca socket for manufacturers of AV receivers, DVD players, and professional mixing consoles requiring high-density input/output panels.

Sony BDP-S3700 RCA Audio Socket's Product Operating Principle

Matrix Integration: The housing stacks connectors in two rows of three, creating a compact grid that allows six signal cables to be connected in a small area.
Signal Isolation: Despite the high density, each port maintains a fully isolated signal pin and dedicated ground contact to ensure signal purity between channels.
Structural Grounding: The unit typically features a unified metal shield or grounding plate that connects to the PCB ground plane, protecting all six channels from electromagnetic interference.

Denon AVR-X540BT RCA Audio Socket's Product Functions

Multi-Channel Interface: Consolidates six individual connection ports into a single housing to support complex signal arrays like 5.1 analog surround sound or Component Video output.
Visual Identification: Incorporates industry-standard color coded insulation rings to visually guide users in connecting the correct video and audio cables during setup.
Space Optimization: Significantly reduces the required printed circuit board footprint and rear panel width compared to installing six separate single-port connectors.
Signal Isolation: Maintains discrete electrical paths for each of the six channels within the matrix block to prevent signal crosstalk and ensure audio-video clarity.

AV Receivers: Integrated into the rear panel of the Denon AVR-X540BT to provide 5.1 channel analog audio inputs for legacy DVD players.

DVD/Blu-ray Players: Used on the output board of the Sony BDP-S3700 to output Component Video and Stereo Audio signals simultaneously.

Professional Audio Mixers: Located on the I/O panel of the Behringer Xenyx 1202 to handle multiple tape inputs and outputs in a compact form factor.
