Single Port Shielded Network Socket with LEDs

Orange Pi 5 RJ45 Socket's Product Introduction

KKG Electronics presents the RJ45-9804 1X1, a high-performance rj45 jack designed to provide both robust connectivity and visual diagnostics. Unlike standard plastic connectors, this unit features a comprehensive metal shield that grounds the port, offering essential protection against electromagnetic interference. It is engineered to securely latch onto a standard Ethernet plug, ensuring a stable physical connection. Ideally suited for any rj45 connector board, it includes built-in LEDs to display network activity without needing extra light pipes on the panel. While distinct from a narrower rj45 connector 4 pin telephony interface, this 8-pin rj45 socket supports full high-speed data transmission. Its reinforced structure serves as a reliable rj45 connector socket for heavy-duty applications, ensuring long-term signal integrity in routers, servers, and embedded systems.

 Netgear ProSAFE GS108 RJ45 Socket's Product Operating Principle

EMI Shielding: The external metal chassis creates a Faraday cage around the connector draining electromagnetic interference to the PCB ground plane to protect signal integrity.
Visual Status Indication: Integrated LED circuits within the housing face illuminate when powered to provide immediate visual feedback on network link status and activity.
Mechanical Retention: The locking tab on the inserted cable plug snaps into the internal recess of the jack securing the cable against accidental removal or vibration.

Advantech ARK-1123 RJ45 Socket's Product Functions

Signal Protection: Prevents data corruption in electrically noisy environments by shielding the sensitive differential Ethernet pairs from external radio frequency interference.
Network Diagnostics: Allows technicians to instantly verify connectivity and data transmission speed via the green and yellow indicators directly on the port face.
Physical Interface: Provides a ruggedized entry point for LAN cabling anchoring the connection securely to the device circuit board to withstand cable tension.
Static Discharge Path: Safely conducts electrostatic discharge (ESD) from the cable shield to the system ground protecting sensitive internal networking components.

Industrial PCs: Integrated into the rear panel of the Advantech ARK-1123 Fanless Box PC to provide shielded LAN connectivity with status indication in factory environments.

Network Switches: Used on the front ports of the Netgear ProSAFE GS108 to indicate link speed and activity for each connected device.

Single Board Computers: Integrated into the I/O of the Orange Pi 5 to provide a robust Gigabit Ethernet interface for DIY projects.

Smart Home Gateways: Located on the rear of the Samsung SmartThings Hub to connect to the home router with visual confirmation of the link.

KKG Electronics uses temperature-resistant materials and high-temperature testing equipment.

The product's appearance does not change when tested at 260°C for 5 minutes!

We ensure high production efficiency and ship your order within 7 days after payment.
