1x2 Right Angle Network Interface Socket

Arduino Ethernet Shield 2 RJ45 Socket's Product Introduction

KKG Electronics presents the RJ45-8104 1X2, a high-efficiency rj45 connector socket designed to double network connectivity in a compact footprint. This "1x2" ganged module integrates two standard Ethernet ports into a single unshielded block, streamlining assembly for multi-port devices. It is engineered to mount securely onto any rj45 connector board, providing a stable anchor for multiple LAN cables simultaneously. While distinct from a basic rj45 connector 4 pin telephone interface, this 8-pin component offers full high-speed data transmission capabilities suitable for modern networking. Its reinforced structure allows it to function effectively as a rj45 connector socket panel mount interface when aligned with device enclosure cutouts. With precision gold-plated contacts, this component ensures consistent signal integrity for routers, set-top boxes, and home automation gateways.

Netgear GS305 RJ45 Socket's Product Operating Principle

Ganged Port Integration: The thermoplastic housing molds two distinct jack cavities side-by-side allowing two independent Ethernet cables to connect to the PCB sharing a common structural alignment.
Spring Contact Engagement: Internal phosphor bronze contacts wipe against the plug blades upon insertion removing oxidation to establish a low-resistance electrical path for data transmission.
Mechanical Latching: Internal ridges within each port capture the locking tab of the Ethernet plugs securing them against accidental removal while maintaining constant contact pressure.

TP-Link Archer C6 RJ45 Socket's Product Functions

Port Expansion: Instantly adds two network interfaces to a device using a single component significantly reducing assembly time compared to soldering two individual jacks.
Signal Interface: Connects external LAN cabling to the device's internal magnetic modules or network controllers enabling simultaneous bidirectional data transfer for two devices.
Structural Rigidity: The multi-leg through-hole footprint anchors the connector firmly to the circuit board distributing the mechanical stress of heavy cables across a wider area.
Cost Efficiency: Reduces the total bill of materials and manufacturing complexity for multi-port devices like switches and routers by utilizing a unified housing design.

Wi-Fi Routers: Integrated into the LAN switch block of the TP-Link Archer C6 to provide wired internet access to multiple home devices.

Unmanaged Switches: Used on the circuit board of the Netgear GS305 to create a compact networking hub for home offices.

VoIP Gateways: Integrated into the interface board of the Grandstream HT812 to facilitate dual analog-to-digital voice connections.

Development Boards: Used on the expansion shield of the Arduino Ethernet Shield 2 to enable network communication for IoT projects.

KKG Electronics uses temperature-resistant materials and high-temperature testing equipment.

The product's appearance does not change when tested at 260°C for 5 minutes!

We ensure high production efficiency and ship your order within 7 days after payment.

Q1: How do you manage production delays caused by unforeseen supply chain disruptions?

A: Our risk-mitigation plan includes buffer stock for critical components and real-time supplier escalation. Clients receive weekly updates and adjusted timelines within 24 hours of disruption identification.

Q2: Are raw materials sourced from conflict-free or ethically certified suppliers?

A: Yes, we adhere to the Responsible Minerals Initiative (RMI) and provide SMETA-audited supply chain reports. All tantalum/tin suppliers are certified conflict-free via OECD Due Diligence.

Q3: How can you ensure the quality?

A:  All our products are 100% tested before delivery. Durable quality is guaranteed.

Q4: Can you modify existing designs to reduce electromagnetic susceptibility (EMS) in high-noise environments?

A: Design revisions like shielded ferrite bead integration or ground plane optimization are available. Our engineers provide EMS simulation reports pre-production.

Q5: What logistics partners do you work with for global distribution?

A: We partner with DHL, FedEx, and regional specialists like SF Logistics (Asia). Customs clearance, HS code labeling, and door-to-door tracking are included.
