Single Port Right Angle PCB Network Interface Socket

Square Register RJ45 Socket's Product Introduction

KKG Electronics presents the RJ45-524H 1X1, a high-quality rj45 connector engineered for robust local area network interfaces. This single-port module utilizes a standard 8P8C configuration housed in a durable unshielded body, making it a cost-effective solution for general networking applications. It is designed to securely engage with a standard rj45 head, providing a tactile locking click that guarantees a stable physical connection. Ideally suited for any rj45 connector board, it features a standard footprint that simplifies integration into printed circuit boards. While primarily a through-hole component, its rigid housing structure allows it to function effectively as a rj45 connector socket capable of aligning with panel cutouts for a flush finish. With its proven durability and precise contact geometry, this component is essential for modems, desktop computers, and industrial control systems requiring reliable data access.

D-Link DGS-1008G RJ45 Socket's Product Operating Principle

Mechanical Locking: The flexible plastic tab on the inserted cable plug snaps into the internal notch of the socket housing to anchor the connection and prevent accidental cable removal.
Spring Contact Wiping: As the plug enters the socket the internal phosphor bronze wire contacts flex and wipe against the plug blades removing surface oxidation to ensure a clean electrical path.
Signal Routing: The internal lead frame directs the differential data signals from the cable interface down through the soldered PCB pins maintaining the necessary impedance for data transfer.

Gigabyte B450M RJ45 Socket's Product Functions

Physical Network Interface: Serves as the primary entry point connecting the device's internal network interface controller (NIC) to the external Local Area Network (LAN) cabling.
Cable Retention: Provides a mechanically secure anchor point that withstands the tension and weight of attached network cables protecting the delicate solder joints on the circuit board.
Standardized Compatibility: Adheres to global TIA/EIA dimensional standards to ensure seamless interoperability with any standard Cat5e or Cat6 Ethernet patch cord.
Electrical Isolation: Maintains proper spacing between the eight conductors to prevent short circuits and minimize crosstalk between the transmit and receive data pairs.

Desktop Motherboards: Integrated into the rear I/O panel of the Gigabyte B450M to provide a hardwired Gigabit Ethernet connection for stable internet access.

VoIP Telephones: Used on the rear port of the Yealink SIP-T46U IP Phone to connect the device to the office network infrastructure.

Network Hubs: Integrated into the circuit board of the D-Link DGS-1008G Switch to provide multiple connection points for office devices.

Point of Sale Systems: Located on the connectivity panel of the Square Register to ensure reliable transaction data transmission via wired LAN.
