10-Pin Right Angle Modular Interface Socket

Digi TransPort WR11 RJ45 Socket's Product Introduction

KKG Electronics presents the RJ45-5603 1X1, a versatile rj45 connector engineered for specialized communication needs. Unlike standard 8-pin jacks, this unit features a 10-pin footprint (10P10C), providing two additional contact points for extra signal routing or grounding while maintaining compatibility with a standard rj45 head. This capability makes it a preferred choice for proprietary data cables found in industrial equipment and point-of-sale systems. The unshielded housing is designed with a low profile to fit into compact enclosures, serving effectively as a rj45 connector socket panel mount interface when aligned with the chassis. Ideally suited for a custom rj45 connector board, it features snap-in plastic pegs for secure retention during soldering. As a robust rj45 jack, it ensures high-reliability connectivity with gold-plated contacts that withstand frequent mating cycles.

Epson TM-T88V RJ45 Socket's Product Operating Principle

10-Pin Configuration: The internal lead frame supports up to 10 conductors allowing for expanded signal routing or standard 8-wire Ethernet use with extra grounding options.
Mechanical Locking: The housing design includes a precise notch that captures the latch of the inserted rj45 head securing the cable against accidental disconnection.
Wiping Contact: Phosphor bronze contacts flex upon plug insertion to wipe away oxidation and establish a low-resistance electrical connection with the cable blades.

AutomationDirect CLICK RJ45 Socket's Product Functions

Physical Network Interface: Serves as the primary entry point connecting the device's internal network interface controller (NIC) to the external Local Area Network (LAN) cabling.
Cable Retention: Provides a mechanically secure anchor point that withstands the tension and weight of attached network cables protecting the delicate solder joints on the circuit board.
Standardized Compatibility: Adheres to global TIA/EIA dimensional standards to ensure seamless interoperability with any standard Cat5e or Cat6 Ethernet patch cord.
Electrical Isolation: Maintains proper spacing between the eight conductors to prevent short circuits and minimize crosstalk between the transmit and receive data pairs.

Barcode Scanners: Integrated into the handle base of the Symbol LS2208 Handheld Scanner to provide a detachable data cable interface via a 10-pin modular connector.

Point of Sale: Used on the peripheral port of the Epson TM-T88V Receipt Printer to connect cash drawers or customer display units.

Industrial Controllers: Located on the communication module of the AutomationDirect CLICK PLC to facilitate proprietary serial communication protocols.

Networking Hardware: Used on the circuit board of the Digi TransPort WR11 Cellular Router to provide a compact local area network connection.
