KKG RCA-K366F: Right Angle Single Port RCA Socket

Oppo Digital RCA Audio Socket's Product Introduction

As a specialist rca socket factory, KKG is pleased to present the RCA-K366F, a single-port connector engineered for precision and durability. This component is the perfect building block for creating custom I/O configurations on printed circuit boards. Its individual, single-port design offers maximum layout flexibility, allowing engineers to place audio and video connections exactly where needed. The robust through-hole mounting creates a strong physical bond to the PCB, ensuring this female rca jack can withstand the stresses of repeated plugging and unplugging.

The right-angle orientation of the RCA-K366F is a critical feature for modern, space-conscious electronics, enabling cable connections that run parallel to the board and allowing for slimmer product profiles. This versatile rca socket can be used for a wide variety of signals, including mono audio, subwoofer outputs, composite video, or S/PDIF digital audio. Built with high-quality materials to ensure excellent signal integrity and a long service life, the KKG RCA-K366F is the reliable choice for any application requiring a single, high-performance RCA connection.

Cambridge Audio CXN V2 RCA Audio Socket's Product Operating Principle

Secure PCB Integration: The through-hole pins are soldered directly to the circuit board, creating a powerful electromechanical connection that ensures signal integrity and durability.

Signal Path Creation: When a male RCA plug is inserted, the internal contacts grip the plug's center pin and outer shield, completing a single, reliable path for an audio or video signal.

Space-Efficient Design: The right-angle orientation allows the body of the connector to sit low on the PCB, saving vertical space within an enclosure.

Denon AVR-X series RCA Audio Socket's Product Functions

Standardized Interface: Provides a universal, single-channel connection point for any standard male RCA cable.

Design Flexibility: The single-port design allows for custom placement and spacing on a PCB for creating custom AV panels.

Durable Mounting: The through-hole design ensures a robust and reliable physical connection to the circuit board.

Signal Versatility: Suitable for transmitting various signals, including mono audio, composite video, or digital coaxial audio.

Subwoofer/LFE Output: Used as the dedicated Low-Frequency Effects (LFE) output on home theater receivers, such as the Denon AVR-X series, for connecting to an active subwoofer.

Digital Audio (S/PDIF): Serves as the coaxial digital audio output on high-fidelity network streamers and DACs, like the Cambridge Audio CXN V2.

Component Video: Utilized in high-end AV equipment where individual jacks are used for each component video signal (Y, Pb, Pr), such as on older Oppo Digital Blu-ray players.
