8 Position SMD Surface Mount Slide Switch DIP-STIM

Raspberry Pi Compute Module 4 DIP Switch's Product Introduction

KKG Electronics introduces the DIP-STIM, a cutting-edge mini dip switch designed for modern Surface Mount Technology (SMT) production lines. Unlike through-hole components, this model features SMD terminals for automated placement and reflow soldering. Its recessed actuators sit flush with the housing, requiring a tool to change the on dip switch status, which prevents accidental changes during handling or from vibration. While a dip switch 4 pins is suitable for basic tasks, this 8-position model provides 256 unique binary codes for complex hardware addressing and configuration. The gold-plated contacts ensure a reliable connection, making it an essential component for high-density, low-profile electronic designs.

Finisar FTLF1318P3BTL DIP Switch's Product Operating Principle

Recessed Slide Mechanism: A small tool is used to move the flush actuator, which repositions the internal wiper to either complete or break the circuit.
SMT Contact Logic: Each of the 8 poles operates as an independent SPST switch, with terminals designed for direct soldering onto PCB pads.
Accidental Change Prevention: The recessed design ensures settings are not inadvertently altered, locking them in place until deliberately changed.

Keyence GV-H130 DIP Switch's Product Functions

Address Configuration: Manually sets unique 8-bit binary addresses for ICs and modules in dense, automated-assembly electronics.
Mode Selection: Allows for the pre-setting of operational modes or parameters at the factory level without firmware changes.
Circuit Setup: Enables or disables specific hardware features on a circuit board, such as test points or optional functionalities.
Firmware-Free Storage: Retains critical system settings permanently through its physical state, requiring no power to maintain configuration.

Industrial Automation: Used on compact industrial sensors like the Keyence GV-H130 Laser Sensor to configure output logic (NPN/PNP) and response time.

Telecommunications: Integrated into SFP optical transceiver modules such as the Finisar FTLF1318P3BTL to set diagnostic modes and compatibility parameters.

Embedded Systems: Located on single-board computers like the Raspberry Pi Compute Module 4 IO Board to configure boot modes and enable/disable peripherals.

KKG Electronics uses temperature-resistant materials and high-temperature testing equipment.

The product's appearance does not change when tested at 260°C for 5 minutes!

We ensure high production efficiency and ship your order within 7 days after payment.
