THT Standard Slide Logic Switch

Schneider Electric Modicon M221 DIP Switch's Product Introduction

KKG Electronics presents the DIP-DS Series, a reliable electronic dip switch designed for universal circuit board compatibility. This series supports standard THT mounting and provides flexible actuator options for finger or tool operation. Despite being a robust module, it functions as a precise micro dip switch, fitting perfectly into standard IC sockets due to its 2.54mm pitch. The 8-way configuration serves as a dependable dip switch 16 pin interface, offering 256 unique binary codes for complex addressing. Built with gold-plated contacts, this component ensures stable electrical continuity, making it a preferred choice for engineers needing a dependable configuration solution.

Dräger Evita V500 DIP Switch's Product Operating Principle

Slide Actuation: The internal slider moves to bridge or separate the gold-plated terminals, establishing the electrical circuit state.
Circuit Logic: Each pole operates independently, creating a binary ON/OFF signal corresponding to the actuator position.
Tactile Feedback: A spring-loaded detent mechanism ensures the switch clicks securely into place, preventing accidental shifting due to vibration.

DSC PowerSeries DIP Switch's Product Functions

Network Addressing: Manually assigns unique node IDs to hardware devices on shared communication buses like RS485 or CAN.
Operational Setup: Configures device modes, such as baud rates, voltage levels, or boot protocols, without requiring software access.
Hardware Debugging: Acts as a physical isolator to disconnect specific circuit blocks during maintenance or testing procedures.
Configuration Storage: Retains system settings mechanically in non-volatile memory, ensuring data persists through power cycles.

Industrial Automation:Used in programmable logic controllers like the Schneider Electric Modicon M221 to configure expansion module addresses and communication speeds.

Medical Electronics: Integrated into the service interface of the Dräger Evita V500 Ventilator to allow technicians to set calibration modes during maintenance.

Security Systems: Located on the main board of the DSC PowerSeries Security Panel to manually configure zone types and sensor sensitivity levels.
