Top Tape Sealed Surface Mount Switch

Philips Hue Bridge DIP Switch's Product Introduction

KKG Electronics presents the KLS7-KPH Series, a premium dip switch smd solution engineered for automated high-volume manufacturing. This model distinguishes itself with a factory-applied Mylar top seal, which protects the internal contacts during reflow soldering and board washing, while also facilitating vacuum suction for pick-and-place machines. utilizing a 1.27mm half-pitch design, it reduces board real estate requirements significantly. While widely used in high-density arrays, the dip switch 6 pins configuration (3-position) is particularly popular for setting precise device addresses in compact modules. The robust PPS housing ensures stability under high temperatures. With gold-plated contacts ensuring reliable logic, users can be confident that every on dip switch toggle results in a stable, noise-free signal for critical electronic systems.

Ubiquiti UniFi Switch DIP Switch's Product Operating Principle

Sealed Slide Mechanism: A recessed slider moves beneath a protective Mylar film, bridging the internal contacts while keeping contaminants out.
Half-Pitch Logic: The switch utilizes a 1.27mm terminal spacing to create independent SPST circuits, enabling high-density binary coding.
SMT Integration: The terminals wrap underneath the body (J-type style), allowing the unit to be reflow soldered directly to the PCB surface.

Mitsubishi MELSERVO-J4 DIP Switch's Product Functions

Process Protection: The integrated Mylar top seal prevents flux ingress during soldering and allows the switch to be washed without damage.
Automated Assembly: The flat, sealed top surface is specifically designed for vacuum nozzles used in high-speed SMT pick-and-place machines.
Space Efficiency: Provides full hardware configuration capabilities in half the footprint of standard switches, ideal for miniaturized electronics.
High-Temp Stability: Built with PPS materials to withstand the rigorous thermal profiles of lead-free reflow ovens.

Industrial Automation: Integrated into the servo amplifier control board of the Mitsubishi MELSERVO-J4 to configure axis addresses and communication parameters.

Networking Equipment: Used in the high-density PCB layout of the Ubiquiti UniFi Switch Enterprise to manually set boot modes and redundancy options.

Smart Home Devices: Located inside the compact housing of the Philips Hue Bridge Smart Hub to configure factory test modes and Zigbee channels.

KKG Electronics uses temperature-resistant materials and high-temperature testing equipment.

The product's appearance does not change when tested at 260°C for 5 minutes!

We ensure high production efficiency and ship your order within 7 days after payment.
