Surface Mount DIP Switch - 2.54mm Pitch

Broadcom MegaRAID 9560-16i DIP Switch's Product Introduction

The KKG DIP-SMD-254 Series is a premier solution for modern electronic designs that require reliable hardware configuration. This dip switch smd is specifically engineered for automated pick-and-place manufacturing, reducing assembly time and cost. Its industry-standard 2.54mm pin pitch ensures wide compatibility with existing PCB layouts. The dip switch 6 pin version, for example, offers 64 unique binary codes for complex logic setting in a compact package. This high-performance dip switch is offered at a competitive dip switch price, making it the ideal choice for both high-volume production and specialized applications.

Focusrite RedNet MP8R DIP Switch's Product Operating Principle

Circuit Configuration: Each individual slide actuator moves an internal gold-plated contact, which either closes (ON) or opens (OFF) a specific electrical circuit path.
Binary Logic Setting: The combination of ON and OFF positions across multiple sliders is read by a microprocessor as a binary code, allowing for multi-level device configuration without firmware changes.
Surface Mount Design: The switch is designed with SMT terminals suitable for reflow soldering, allowing for efficient and precise placement on the surface of a PCB.

Cisco Catalyst 2960 DIP Switch's Product Functions

Hardware Address Setting: Allows a unique address to be assigned to a device on a shared data bus, common in industrial control and networking systems.
Mode Selection: Provides a simple, reliable hardware method for setting a device's operational mode or enabling specific features that are not meant to be changed by the end-user.
Configuration Control: Offers a physical way to set parameters like baud rates, termination, or gain settings in telecommunications and test equipment.
Cost-Effective Variants: Enables manufacturers to use a single PCB design to create multiple product versions by simply changing the switch settings.

Networking Hardware: Used on network switches like the Cisco Catalyst 2960 series for initial boot-up and recovery mode settings.

Professional Audio: Integrated into Dante-enabled audio interfaces like the Focusrite RedNet MP8R to set device IDs and configuration parameters on a network.

Data Storage: Found on server RAID controller cards, such as the Broadcom MegaRAID 9560-16i, to configure boot modes or enable specific card features.
