Rotary Dip Switch

Home > Products > SMD Type

A code switch is a digital input switch that outputs a binary code signal based on the mechanical position of the switch. Rotation of the knob drives the adjustable encoder disc and encoder plate via the switch handle, recording the angular change of the knob. Different binary codes are marked on the adjustable encoder disc and encoder plate. When the switch is operated, pressing the button causes the adjustable encoder disc and encoder plate to rotate together. The contacts on the encoder plate engage with the wires on the adjustable encoder disc, outputting corresponding control signals based on the connected binary code to achieve the switch control function.

Rotary Coding Switch

Rotary Coding Switch

the rotary shaft of the rotary coding switch is the core part of the rotary coding switch, which is responsible for the rotary movement of the rotary switch and detects the direction and angle of rotation through the rotary encoder, thus realizing the control of the circuit.

Rotary Coded Switch

Rotary Coded Switch

Rotary Coded switches are a common type of electric control switch, widely used in machinery, electronics and other fields, commonly used in control devices, counters, sensors and other electronic equipment. So, what is the working principle of coding switch? In this article, we will introduce the components, working principle and application of coding switch.

Application Areas

Industry Equipment Household Application Automotive Areas Medical Equipment
