USB 3.1 Type-A Connector

Product Description

The USB 3.1 Type-A connector is a high-performance USB Type A interface designed for stable, high-speed data transmission in automotive, industrial, and consumer electronics applications. This Type A connector adopts a vertical 180° DIP structure with straight pins, supporting up to 5Gbps data transfer, making it ideal for modern devices requiring reliable USB connectivity.

Unlike USB C 3.1, which features reversible insertion, this USB Type A solution provides mechanical robustness and wide compatibility with legacy and next-generation systems. It is commonly used together with USB-C to USB-A cables, USB 3.1 adapters, and conversion solutions such as USB 3.1 Gen 1 to USB C and USB 3.1 Gen 2 to USB C interfaces.

The no-rolled-edge housing design simplifies PCB assembly, while wave soldering ensures excellent durability in high-vibration and harsh environments.

Product Operating Principle

This USB 3.1 Type-A connector uses a vertical 180° DIP mounting configuration, enabling straight-pin signal transmission directly to the PCB. High-speed differential pairs support USB 3.1 Gen 1 (5Gbps) data rates with low signal loss.

The robust mechanical structure ensures stable contact during vibration, making it suitable for automotive diagnostic ports and industrial control systems. The connector supports seamless interaction with USB C to USB A cables and various USB 3.1 adapters, enabling flexible system integration.

Key Features

• High-Speed USB 3.1 Performance
  Supports up to 5Gbps data transfer for fast communication

• Vertical 180° DIP Design
  Optimizes PCB space and improves mechanical stability

• Industrial-Grade Construction
  Reliable operation from -40°C to +85°C

• No Rolled Edge Structure
  Simplifies PCB layout and assembly

• Wave Soldering Compatible
  Ensures strong solder joints and long service life

• Wide Compatibility
  Works with USB C 3.1, USB C to USB A, and USB 3.1 adapter solutions

Product Advantages

• Stable Signal Transmission
  Straight-pin design minimizes signal interference and data loss

• Excellent Durability
  Resistant to shock, vibration, and thermal stress

• Space-Saving Layout
  Vertical mounting reduces horizontal PCB footprint

• Strong System Compatibility
  Easily integrates with USB Type A ports and USB-C conversion systems

• Cost-Effective & Reliable
  Ideal alternative to more complex USB-C only designs

Application Scenarios

Automotive Electronics

• Bosch OBD-II Scanners – Diagnostic ports for vehicle data access

• Tesla Model 3 Infotainment Systems – Stable USB interface for diagnostics and updates

Consumer Electronics

• Samsung Galaxy Tablets – USB hub and peripheral connectivity

• LG Monitors – USB hub expansion using USB Type A ports

Industrial Control Systems

• Siemens PLCs – Data transfer and firmware updates

• Rockwell Automation Panels – Data logging and system interface

Compatibility & Interface Expansion

This USB 3.1 Type-A connector is commonly used with:

• USB C to USB A cables

• USB 3.1 adapter modules

• USB 3.1 Gen 1 to USB C solutions

• USB 3.1 Gen 2 to USB C backward-compatible systems

It provides a reliable bridge between traditional USB Type A interfaces and modern USB C 3.1 devices.

Conclusion

The USB 3.1 Type-A connector offers a perfect balance of speed, durability, and compatibility. With its vertical DIP design, industrial-grade reliability, and support for modern USB 3.1 ecosystems, it is an ideal solution for automotive electronics, consumer devices, and industrial control systems.

If you need a robust USB Type A connector that works seamlessly with USB-C to USB-A and USB 3.1 adapter solutions, this connector delivers dependable performance in demanding environments.

KKG Electronics, each part of the use of temperature-resistant materials, high-temperature testing equipment 260 ℃ for 5 minutes, the appearance of the product does not change!

High effiency of production, shipped in 1 day after payment.

Q1: Are you a manufacturer or a trading company?

A: We are a manufacturing company with over 15 years of expertise in producing switches, sockets, connectors, DC jacks, and related components.

Q2: How long does it take for delivery?
A: For popular models, we typically have them in stock for immediate shipment. For other models, the lead time is generally a few days.

Q3: How do you ensure product quality?
A: Every product undergoes thorough testing to guarantee 100% functionality before dispatch. We are dedicated to delivering reliable and long-lasting products.

Q4: What kind of packaging do you use?
A: Our products are carefully packed in inner boxes with robust outer cartons to ensure safe delivery and protection during transit.

Q5: What payment methods do you accept?
A: For smaller orders, we recommend PayPal. For larger orders, payments can be made via T/T (bank transfer).
