3-Position DP3T Through-Hole Slide Switch

Bosch Engine Control Unit (ECU) Slide Switch's Product Introduction

The KKG SK23E03 is a versatile and robust slide switch pcb component, engineered for applications requiring multi-state, dual-circuit control. Its DP3T (Double Pole, Three Throw) configuration offers advanced functionality, far exceeding that of a simple on off slide switch or a standard slide switch 2 position model. This allows a single actuator to manage two separate circuits across three distinct modes. The strong through-hole pins ensure a secure and lasting connection to the circuit board, providing excellent mechanical stability for frequent use. This component is a go-to choice for any design requiring a dependable, multi-functional switch with a clear tactile feel.

Schiit Freya S Slide Switch's Product Operating Principle

Through-Hole Stability: The switch's pins are inserted through holes in a PCB and soldered on the reverse side, providing a very strong mechanical and electrical bond that withstands physical stress.
Dual-Pole, 3-Throw Actuation: A single mechanical actuator is internally linked to two separate poles (contacts), allowing them to switch in unison across three distinct terminal positions.
Vertical Operation: The top-mounted actuator provides a simple, physical interface for the user to manually change the state of the switch between its three distinct latching positions.

Dayton Electric Slide Switch's Product Functions

Complex Signal Routing: Enables the simultaneous redirection of two separate signals (e.g., stereo audio) to one of three different destinations, perfect for input selection or effects routing.
Multi-Mode Functionality: Allows a device to be placed in one of three unique operational modes by controlling two different aspects of the circuit for each mode (e.g., Forward/Off/Reverse).
Component Consolidation: Replaces the need for multiple switches or a larger rotary switch, saving valuable board space and simplifying the user interface.
Advanced Power Control: Can be wired to provide complex power states for two circuits, such as High/Medium/Low settings for dual-element heaters or fans.

Audio Equipment: Used as an input selector or filter switch on stereo preamplifiers like the Schiit Freya S, allowing two channels to be switched between three different inputs.

Industrial Controls: Serves as a manual motor control switch, for instance, on a custom panel for a Dayton Electric motor to provide Forward, Off, and Reverse states for two windings.

Test and Measurement Jigs: Integrated into custom test equipment to switch two separate data lines (e.g., RX/TX) between three different devices under test.
