Right Angle 12-Pin 4-Position Slide Switch

Korg MS-20 Slide Switch's Product Introduction

The KKG SK24D01 is a high-performance slide switch engineered for complex signal routing and multi-mode selection. Its advanced DP4T (Double Pole, 4-Throw) configuration allows a single actuator to manage two independent circuits across four distinct states. The robust through-hole slide switch pcb mount design ensures a secure, lasting connection to the board, ideal for applications requiring mechanical strength. When you need a reliable interface to slide the switch between multiple complex functions, this component delivers. The actuator is also ready to accept a custom slide switch cap for a professional, user-friendly finish.

Tektronix AFG31000 Slide Switch's Product Operating Principle

Right-Angle Stability: The through-hole pins are soldered into the PCB, allowing the switch body to sit flat while the side-actuator provides operation parallel to the board, perfect for edge-of-board access.
Dual-Pole, 4-Throw Control: A single actuator moves two independent internal contacts (poles) across four distinct sets of terminals, connecting each pole to one of its four corresponding "throw" outputs.
Horizontal Actuation: The side-mounted actuator provides a simple, durable physical interface for the user to manually change the state of the switch between its four latching positions.

Allen & Heath Xone:96 Slide Switch's Product Functions

Complex Signal Routing: Enables the simultaneous redirection of two separate signals (e.g., stereo audio) to one of four different destinations, ideal for an input selector on an amplifier or mixer.
Multi-Mode Functionality: Allows a device to be placed in one of four unique operational modes by controlling two different aspects of the circuit for each mode.
Component Consolidation: Replaces the need for a larger rotary switch or a complex bank of individual switches, saving significant board space and simplifying the user interface.
Advanced Test Configuration: Provides a reliable physical method for setting up complex test scenarios, routing two signals to four different test points or configurations in a test jig.

Professional Audio Equipment: Used as an input selector on a high-end audio mixer like the Allen & Heath Xone:96, to switch a stereo channel between four different sources (e.g., Phono, Line, USB 1, USB 2).

Test and Measurement Gear: Serves as a primary function selector on a benchtop device, for example, a custom interface for a Tektronix AFG31000 arbitrary function generator to route two channels to four different test fixtures.

Vintage Synthesizer Replicas: Integrated into recreations of classic synthesizers, such as a DIY clone of the Korg MS-20, to manage complex signal patching and routing between modules.
