Right Angle 3-Position DP3T Slide Switch

Electro-Harmonix Pitch Fork Slide Switch's Product Introduction

The KKG SK43D03 is a high-performance slide switch pcb component engineered for multi-function control and durability. Its DP3T (Double Pole, Three Throw) configuration allows a single actuator to control two independent circuits across three distinct states, making it a powerful slide switch on off on for complex signal routing. The right-angle, through-hole design provides a secure and lasting connection to the board, perfect for edge-mounted controls. The large actuator is designed to be a user-friendly slide switch button, providing clear tactile feedback. This switch offers exceptional functionality at a great slide switch price, making it ideal for professional audio, industrial controls, and more.

Siglent SDG2042X Slide Switch's Product Operating Principle

Right-Angle Mounting: The through-hole pins are soldered into the PCB, allowing the switch body to sit flat while the side-actuator provides operation parallel to the board.
Dual-Pole, 3-Throw Control: A single actuator moves two independent internal contacts (poles) across three distinct sets of terminals, connecting each pole to one of its three corresponding "throw" outputs.
Horizontal Operation: The side-mounted actuator provides a simple, durable physical interface for the user to manually change the state of the switch between its three latching positions.

Universal Audio Apollo Twin Slide Switch's Product Functions

Complex Signal Routing: Enables the simultaneous redirection of two separate signals (e.g., stereo audio) to one of three different destinations, ideal for an input selector.
Multi-Mode Functionality: Allows a device to be placed in one of three unique operational modes by controlling two different aspects of the circuit for each mode.
Component Consolidation: Replaces the need for multiple switches or a larger rotary switch, saving valuable board space and simplifying the user interface.
Motor Control with Off State: Can be wired to control a DC motor with three distinct states: Forward, Off (center position), and Reverse, by managing both power lines.

Audio Interfaces: Used as an input selector on professional audio interfaces like the Universal Audio Apollo Twin, to switch a stereo input between Mic, Line, and Hi-Z.

Test and Measurement Equipment: Serves as a primary mode selector on a benchtop function generator, for example, on a custom interface for a Siglent SDG2042X, to switch two output channels between different waveform families.

Guitar Effects Pedals: Integrated into multi-function guitar pedals, such as the Electro-Harmonix Pitch Fork, to select between different pitch-shifting modes (Up, Down, Dual).
