Single Pole 3-Position Slide Switch

KKG MS-13D20 SP3T Slide Switch – 3 Position Control PCB Solution

The KKG MS-13D20 is a high-reliability slide switch electronic component designed for precision signal routing and multi-state control in compact electronic systems. As a durable PCB slide switch, it provides stable performance for industrial equipment, audio devices, testing instruments, and consumer electronics. Its single pole 3 position slide switch structure allows seamless selection between three independent circuit paths, making it a flexible solution for modern electronic design requirements.

This component is a true SP3T slide switch engineered with through-hole mounting for superior mechanical strength compared to fragile surface-mount alternatives. Whether used in prototyping or mass production, this mini slide switch delivers consistent tactile feedback and long service life.

Product Description

The MS-13D20 functions as a 3 position slide switch that enables a single input signal to be routed across three output terminals. Its internal contact system is designed for smooth switching action and stable electrical connectivity. With a rated 300mA / 6V DC capacity, it is suitable for low-power signal control applications.

Unlike standard switches, this PCB slide switch ensures strong PCB fixation through through-hole pins, making it ideal for environments with frequent manual operation or vibration exposure.

Key Features

• True single pole 3 position slide switch configuration

• Reliable SP3T slide switch architecture for multi-circuit selection

• Compact mini slide switch design for space-saving PCB layouts

• Durable slide switch electronic component with long mechanical life

• Strong through-hole structure for secure PCB mounting

• Smooth tactile sliding mechanism with clear position feedback

Advantages

• High Durability: Rated for 10,000+ switching cycles

• Stable Performance: Low contact resistance (≤30mΩ)

• Safe Operation: 100MΩ insulation resistance for signal integrity

• Easy Integration: Standard PCB footprint for fast assembly

• Flexible Design: Replaces multiple switches or rotary selectors

This 3 position slide switch significantly simplifies circuit design while improving user interface efficiency.

Applications

• Audio and video equipment signal routing

• Industrial control panels

• Test and measurement devices

• Consumer electronics (fans, toys, appliances)

• Communication devices and embedded systems

• Prototyping and PCB development projects

The versatility of this PCB slide switch makes it suitable for both professional and commercial electronics.

Technical Parameters

FAQ

Q1: What is a SP3T slide switch used for?
A SP3T slide switch is used to route a single signal to one of three output paths, commonly used in mode selection or signal switching applications.

Q2: Is this a mini slide switch suitable for compact devices?
Yes, its compact design makes it ideal as a mini slide switch for space-limited PCB layouts.

Q3: Can this slide switch electronic component handle frequent use?
Yes, it is rated for at least 10,000 cycles with stable mechanical performance.

Q4: Is this PCB slide switch suitable for industrial environments?
Yes, its through-hole structure ensures strong PCB mounting and vibration resistance.

Q5: What is the advantage of using a slide switch electronic component instead of a rotary switch?
A slide switch electronic component is more compact, easier to operate, and saves PCB space compared to rotary switches, while still providing reliable multi-position control.

The KKG MS-13D20 is a reliable and efficient 3 position slide switch solution for engineers seeking durability, precision, and compact design in a single slide switch electronic component.

Professional Audio Equipment: Used as an input gain or filter selector on mixing consoles like the Soundcraft Signature Series, allowing a channel to switch between "High Pass," "Flat," and "Low Pass" filter settings.

Test and Measurement Gear: Serves as a function selector on multimeters or signal generators, for example, switching the output of a Keysight 33500B Series generator between Sine, Square, and Triangle waveforms.

Electric Guitars and Basses: Employed in custom guitar wiring for coil-tapping a humbucker pickup, allowing the player to select between "Series," "Split-Coil," and "Parallel" tones.

KKG Electronics uses temperature-resistant materials and high-temperature testing equipment.

The product's appearance does not change when tested at 260°C for 5 minutes!

We ensure high production efficiency and ship your order within 7 days after payment.
